Executive Product Summary
The Danfoss 030B8520 is an OD B-type oil nozzle engineered for reliable combustion performance. It features a precise capacity of 7.5 gal/h (29.8 kg/h) and produces a 45° semi solid (B) spray pattern. Constructed with a conical shape, the nozzle operates without a filter or LE anti-drip valve. Supplied in industrial packs of 50 pieces, the product complies with China RoHS and EU RoHS directives (subject to exemption 6(c)). The REACH Candidate List notes the presence of Lead (CAS no. 7439-92-1) under SCIP dossier number 2f422372-944a-4f60-b35a-2df235377320. Visual analysis confirms a standard threaded brass body. The product page was accessed but contained no additional technical data beyond the specification tables provided.
Cross-Compatibility & System Integration
The Danfoss 030B8520 operates at a standardized reference point of 7 bar, 3.4 cSt, and 820 kg/m³, with a specification point defined at 10 bar, 3.4 cSt, and 840 kg/m³. It is packaged in an industrial format containing 50 pieces per pack. No specific system compatibility or integration data beyond the reference and specification point conditions listed in the Technical Specifications table was available for this product. Buyers should confirm compatibility with their burner or boiler OEM specifications.
Frequently Asked Questions
Q: What is the flow capacity of the Danfoss 030B8520?
The nozzle has a rated capacity of 7.5 gal/h, which is equivalent to 29.8 kg/h.
Q: What spray angle and pattern does the Danfoss 030B8520 produce?
It produces a 45° semi solid spray pattern, denoted by the marking 'B'.
Q: Does the Danfoss 030B8520 use a filter?
No, this model does not include a filter (Filter type: None).
Q: What are the reference test conditions for the Danfoss 030B8520?
The reference point conditions are 7 bar pressure, 3.4 cSt viscosity, and 820 kg/m³ density.
Q: Where can I order the Danfoss 030B8520 with DDP delivery?
You can request a quote from Growthbet LTD by emailing sales@growthbet.net.
Source This Product From Growthbet LTD
Growthbet LTD is a UK-registered global industrial procurement company specializing in sourcing and delivering technical components under a full-liability DDP (Delivered Duty Paid) model. When you source through Growthbet, the company assumes complete responsibility for supplier verification, quality control, international freight, customs clearance, and last-mile delivery to your facility — with a single, transparent invoice and no hidden costs.
- Bulk & Project Pricing: Competitive DDP landed-cost quotations for any volume, from single units to full-container orders.
- 48-Hour Quotation Response: Submit your specifications and quantity, and receive a formal sourcing brief within 48 hours.
- Global Delivery: DDP shipping to the GCC, United Kingdom, Europe, United States, Australia, and worldwide.
- Verified Supply Chain: Every supplier is factory-audited and certification-verified before any order is placed.
&ud83d&udce7 Request a Quote: Email sales@growthbet.net with the product name, quantity, and delivery destination. &ud83d&udcde Call: +44 7897470885.
